AC配置

AC6003>display   current-configuration

Software Version V200R010C00SPC700

#

http server load sdcard:/AC6003V200R010C00SPC700.001.web.7z

http secure-server ssl-policy default_policy

http server enable

#

clock timezone BeijingChongqingHongkongUrumqi add 08:00:00

#

vlan batch 10 20

#

authentication-profile name default_authen_profile

authentication-profile name dot1x_authen_profile

authentication-profile name mac_authen_profile

authentication-profile name macportal_authen_profile

authentication-profile name portal_authen_profile

#

undo lldp enable

#

diffserv domain default

#

radius-server template default

#

pki realm default

rsa local-key-pair default

enrollment self-signed

#

ssl policy default_policy type server

pki-realm default

version tls1.0 tls1.1 tls1.2

ciphersuite rsa_aes_128_cbc_sha rsa_aes_128_sha256 rsa_aes_256_sha256

#

ike proposal default

encryption-algorithm aes-256

dh group14

authentication-algorithm sha2-256

authentication-method pre-share

integrity-algorithm hmac-sha2-256

prf hmac-sha2-256

#

free-rule-template name default_free_rule

#

portal-access-profile name portal_access_profile

#

aaa

authentication-scheme default

authentication-scheme radius

  authentication-mode radius

authorization-scheme default

accounting-scheme default

domain default

  authentication-scheme default

domain default_admin

  authentication-scheme default

local-user admin password irreversible-cipher $1a$*-E\8hVBAP$0]\K1YM{q5.M.&.4XvaL)!g`0vE&&Bzl8)8f]]J3$

local-user admin privilege level 15

local-user admin service-type telnet terminal ssh http

#

interface Vlanif1

ip address 10.1.1.6 255.255.255.0

#

interface Ethernet0/0/47

ip address 169.254.3.1 255.255.255.0

#

interface GigabitEthernet0/0/1

port link-type trunk

port trunk allow-pass vlan 2 to 4094

#

interface GigabitEthernet0/0/2

#

interface GigabitEthernet0/0/3

#

interface GigabitEthernet0/0/4

#

interface GigabitEthernet0/0/5

#

interface GigabitEthernet0/0/6

#

interface GigabitEthernet0/0/7

#

interface GigabitEthernet0/0/8

#

interface NULL0

#

info-center timestamp log date precision-time millisecond

info-center timestamp trap date precision-time millisecond

#

undo snmp-agent

#

stelnet server enable

undo telnet ipv6 server enable

ssh server secure-algorithms cipher aes256_ctr aes128_ctr

ssh server secure-algorithms hmac sha2_256

ssh server key-exchange dh_group14_sha1

ssh client secure-algorithms cipher aes256_ctr aes128_ctr

ssh client secure-algorithms hmac sha2_256

ssh client key-exchange dh_group14_sha1

#

ip route-static 0.0.0.0 0.0.0.0 10.1.1.1

#

capwap source interface vlanif1

#

user-interface con 0

authentication-mode aaa

user-interface vty 0 4

authentication-mode aaa

protocol inbound all

user-interface vty 16 20

protocol inbound all

#

wmi-server

collect-item log-data disable

#

wmi-server2

collect-item log-data disable

#

wlan

traffic-profile name RXJS

  undo traffic-optimize bcmc unicast-send dhcp

traffic-profile name default

  undo traffic-optimize bcmc unicast-send dhcp

security-profile name RXJS

  security wpa-wpa2 psk pass-phrase %^%#{<6->b6Xx=Z6#W)$iRIX;KOW"WEW:H2zsBO(zB|+%^%# aes-tkip

security-profile name default

security-profile name RXJS-Guest

  security wpa-wpa2 psk pass-phrase %^%#=n#F1'87#,K0{)SR`mtS,><AJi!"O~9gd~"v'&c(%^%# aes-tkip

security-profile name default-wds

  security wpa2 psk pass-phrase %^%#qNfI(V#y8:b/W|/(mY81#Z\D8~!8Y*#IO1RwV);+%^%# aes

security-profile name default-mesh

  security wpa2 psk pass-phrase %^%#o[7"I"t]\4xd-e7_BV:3&kdR~nCGO!El4DSuB>~E%^%# aes

ssid-profile name RXJS

  ssid RXJS

  mu-mimo disable

ssid-profile name default

  mu-mimo disable

ssid-profile name RXJS-Guest

  ssid RXJS-Guest

vap-profile name RXJS

  forward-mode tunnel

  service-vlan vlan-id 10

  ssid-profile RXJS

  security-profile RXJS

  traffic-profile RXJS

vap-profile name default

vap-profile name RXJS-Guest

  forward-mode tunnel

  service-vlan vlan-id 20

  ssid-profile RXJS-Guest

  security-profile RXJS-Guest

wds-profile name default

  mu-mimo disable

mesh-handover-profile name default

mesh-profile name default

regulatory-domain-profile name default

  dca-channel 5g channel-set 36,40,44,48,52,56,60,64,149,153,157,161

  dca-channel 5g bandwidth 80mhz

  channel-load-mode indoor

air-scan-profile name default

rrm-profile name default

  smart-roam disable

  sta-load-balance dynamic disable

radio-2g-profile name default

radio-5g-profile name default

wids-profile name default

wireless-access-specification

ap-system-profile name default

  lldp report enable

  traffic-optimize broadcast-suppression arp disable

  traffic-optimize broadcast-suppression igmp disable

  traffic-optimize broadcast-suppression nd disable

  traffic-optimize broadcast-suppression other-broadcast disable

  traffic-optimize broadcast-suppression other-multicast disable

port-link-profile name default

wired-port-profile name default

ap auth-mode no-auth

ap-group name default

  radio 0

   vap-profile RXJS wlan 1

   vap-profile RXJS-Guest wlan 2

  radio 1

   vap-profile RXJS wlan 1

   vap-profile RXJS-Guest wlan 2

  radio 2

   vap-profile RXJS wlan 1

   vap-profile RXJS-Guest wlan 2

ap-id 0 type-id 49 ap-mac 446a-2e28-0ba0 ap-sn 21500827008WJ1000939

ap-id 1 type-id 49 ap-mac 10c1-721d-3de0 ap-sn 21500836298WJB002899

ap-id 2 type-id 49 ap-mac 446a-2e28-0be0 ap-sn 21500827008WJ1000941

ap-id 3 type-id 49 ap-mac 10c1-721d-7d00 ap-sn 21500836298WJB003404

ap-id 4 type-id 49 ap-mac 2028-3e15-1580 ap-sn 21500836298WJB015331

ap-id 5 type-id 49 ap-mac 10c1-721d-67e0 ap-sn 21500836298WJB003235

ap-id 6 type-id 49 ap-mac 2028-3e15-17a0 ap-sn 21500836298WJB015348

ap-id 7 type-id 49 ap-mac 446a-2e28-0b00 ap-sn 21500827008WJ1000934

ap-id 8 type-id 49 ap-mac 446a-2e28-0b40 ap-sn 21500827008WJ1000936

provision-ap

ap update update-filename FitAP5030DN-S_V200R010C00SPCc00.bin ap-type 49 ap-group default

#

device-profile profile-name @default_device_profile

device-type default_type_phone

enable

rule 0 user-agent sub-match Android

rule 1 user-agent sub-match iPhone

rule 2 user-agent sub-match iPad

if-match rule 0 or rule 1 or rule 2

#

dot1x-access-profile name dot1x_access_profile

#

mac-access-profile name mac_access_profile

#

undo ntp-service enable

#

return

华为核心

[CoreSW]display current-configuration

!Software Version V200R010C00SPC600

#

sysname CoreSW

#

vlan batch 10 20 99

#

authentication-profile name default_authen_profile

authentication-profile name dot1x_authen_profile

authentication-profile name mac_authen_profile

authentication-profile name portal_authen_profile

authentication-profile name dot1xmac_authen_profile

authentication-profile name multi_authen_profile

#

telnet server enable

#

lldp enable

#

dhcp enable

#

diffserv domain default

#

radius-server template default

#

acl number 2000

rule 5 deny source 172.25.2.0 0.0.0.255

rule 10 permit

#

acl number 3000

rule 5 deny ip source 172.25.2.0 0.0.0.255 destination 172.25.0.0 0.0.1.255

rule 10 deny ip source 172.25.2.0 0.0.0.255 destination 10.1.1.0 0.0.0.255

rule 15 permit ip source 172.25.2.0 0.0.0.255

#

free-rule-template name default_free_rule

#

portal-access-profile name portal_access_profile

#

drop-profile default

#

ip pool Vlan10

gateway-list 172.25.0.1

network 172.25.0.0 mask 255.255.254.0

excluded-ip-address 172.25.1.230 172.25.1.254

lease day 3 hour 0 minute 0

dns-list 114.114.114.114

#

ip pool Vlan20

gateway-list 172.25.2.1

network 172.25.2.0 mask 255.255.255.0

lease day 2 hour 0 minute 0

dns-list 114.114.114.114

#

ip pool Vlan1

gateway-list 10.1.1.1

network 10.1.1.0 mask 255.255.255.0

excluded-ip-address 10.1.1.2 10.1.1.150

lease day 3 hour 0 minute 0

dns-list 114.114.114.114

#

aaa

authentication-scheme default

authentication-scheme radius

  authentication-mode radius

authorization-scheme default

accounting-scheme default

local-aaa-user password policy administrator

  password history record number 0

  password expire 0

local-aaa-user password policy access-user

domain default

  authentication-scheme radius

  radius-server default

domain default_admin

  authentication-scheme default

local-user admin password irreversible-cipher $1a$R=B~X_8/;N$A!&wA@U\~*#o2b88he"7`pq-;Jfec'M=WrShJ82W$

local-user admin privilege level 15

local-user admin service-type telnet terminal ftp

#

interface Vlanif1

ip address 10.1.1.1 255.255.255.0

dhcp select global

#

interface Vlanif10

ip address 172.25.0.1 255.255.254.0

dhcp select global

#

interface Vlanif20

ip address 172.25.2.1 255.255.255.0

dhcp select global

#

interface Vlanif99

ip address 10.0.0.1 255.255.255.0

#

interface MEth0/0/1

#

interface GigabitEthernet0/0/1

port link-type trunk

port trunk allow-pass vlan 2 to 4094

#

interface GigabitEthernet0/0/2

port link-type access

port default vlan 10

#

interface GigabitEthernet0/0/3

port link-type trunk

port trunk allow-pass vlan 2 to 4094

#

interface GigabitEthernet0/0/4

port link-type trunk

port trunk allow-pass vlan 2 to 4094

#

interface GigabitEthernet0/0/5

port link-type trunk

port trunk allow-pass vlan 2 to 4094

#

interface GigabitEthernet0/0/6

port link-type trunk

port trunk allow-pass vlan 2 to 4094

#

interface GigabitEthernet0/0/7

#

interface GigabitEthernet0/0/8

#

interface GigabitEthernet0/0/9

port link-type access

port default vlan 10

#

interface GigabitEthernet0/0/10

#

interface GigabitEthernet0/0/11

#

interface GigabitEthernet0/0/12

#

interface GigabitEthernet0/0/13

#

interface GigabitEthernet0/0/14

#

interface GigabitEthernet0/0/15

#

interface GigabitEthernet0/0/16

#

interface GigabitEthernet0/0/17

port link-type access

port default vlan 10

#

interface GigabitEthernet0/0/18

port link-type access

port default vlan 10

#

interface GigabitEthernet0/0/19

port link-type access

port default vlan 10

#

interface GigabitEthernet0/0/20

port link-type access

port default vlan 10

#

interface GigabitEthernet0/0/21

port link-type access

port default vlan 10

#

interface GigabitEthernet0/0/22

#

interface GigabitEthernet0/0/23

#

interface GigabitEthernet0/0/24

port link-type access

port default vlan 99

#

interface GigabitEthernet0/0/25

#

interface GigabitEthernet0/0/26

#

interface GigabitEthernet0/0/27

#

interface GigabitEthernet0/0/28

#

interface XGigabitEthernet0/0/1

#

interface XGigabitEthernet0/0/2

#

interface XGigabitEthernet0/0/3

#

interface XGigabitEthernet0/0/4

#

interface NULL0

#

ip route-static 0.0.0.0 0.0.0.0 10.0.0.2

#

traffic-filter vlan 20 inbound acl 3000

#

user-interface con 0

authentication-mode aaa

user-interface vty 0 4

acl 2000 inbound

authentication-mode aaa

protocol inbound all

user-interface vty 16 20

#

dot1x-access-profile name dot1x_access_profile

#

mac-access-profile name mac_access_profile

#

return

[CoreSW] dis

[CoreSW] display ip int

[CoreSW] display ip interface br

[CoreSW] display ip interface brief

*down: administratively down

^down: standby

(l): loopback

(s): spoofing

(E): E-Trunk down

The number of interface that is UP in Physical is 5

The number of interface that is DOWN in Physical is 1

The number of interface that is UP in Protocol is 5

The number of interface that is DOWN in Protocol is 1

Interface                         IP Address/Mask      Physical   Protocol

MEth0/0/1                         unassigned           down       down

NULL0                             unassigned           up         up(s)

Vlanif1                           10.1.1.1/24          up         up

Vlanif10                          172.25.0.1/23        up         up

Vlanif20                          172.25.2.1/24        up         up

Vlanif99                          10.0.0.1/24          up         up

华为防火墙

<USG6300>display current-configuration

2021-12-01 10:47:02.840 +08:00

!Software Version V500R005C00SPC100

#

sysname USG6300

#

FTP server enable

#

l2tp domain suffix-separator @

#

authentication-profile name portal_authen_default

#

ipsec sha2 compatible enable

#

undo factory-configuration prohibit

#

undo telnet server enable

undo telnet ipv6 server enable

#

clock timezone Beijing add 08:00:00

#

update schedule location-sdb weekly Sun 23:28

#

firewall defend action discard

#

log type traffic enable

log type syslog enable

log type policy enable

#

undo dataflow enable

#

undo sa force-detection enable

#

banner enable

#

user-manage web-authentication security port 8887

page-setting

user-manage security version tlsv1.1 tlsv1.2

password-policy

level high

user-manage single-sign-on ad

user-manage single-sign-on tsm

user-manage single-sign-on radius

user-manage auto-sync online-user

#

firewall ids authentication type aes256

#

web-manager security version tlsv1.1 tlsv1.2

web-manager enable

web-manager security enable

undo web-manager config-guide enable

#

firewall dataplane to manageplane application-apperceive default-action drop

#

update schedule ips-sdb daily 22:00

update schedule av-sdb daily 22:00

update schedule sa-sdb daily 22:00

update schedule ip-reputation daily 22:00

update schedule cnc daily 22:00

update schedule file-reputation daily 22:00

#

set disk-scan parameter attach on

set disk-scan parameter cycle 15

set disk-scan parameter iostat 80

set disk-scan parameter speed 10

set disk-scan parameter switch on

set disk-scan parameter parallel 50

disk-usage alarm threshold 95

#

ip vpn-instance default

ipv4-family

#

ip address-set Office_client type object

address 0 172.25.0.0 mask 16

address 1 10.1.0.0 mask 16

#

time-range worktime

  period-range 08:00:00 to 18:00:00 working-day

#

ike proposal default

encryption-algorithm aes-256 aes-192 aes-128

dh group14

authentication-algorithm sha2-512 sha2-384 sha2-256

authentication-method pre-share

integrity-algorithm hmac-sha2-256

prf hmac-sha2-256

#

web-auth-server default

port 50100

#

portal-access-profile name default

#

aaa

authentication-scheme default

authentication-scheme admin_local

authentication-scheme admin_radius_local

authentication-scheme admin_hwtacacs_local

authentication-scheme admin_ad_local

authentication-scheme admin_ldap_local

authentication-scheme admin_radius

authentication-scheme admin_hwtacacs

authentication-scheme admin_ad

authentication-scheme admin_ldap

authorization-scheme default

accounting-scheme default

domain default

  service-type internetaccess ssl-vpn l2tp ike

  internet-access mode password

  reference user current-domain

manager-user audit-admin

  password cipher @%@%G~BiV3r0c/2Veh'.uBP>2&[83":m)"T=#.z0bY~c|o>'&[;2@%@%

  service-type web terminal

  level 15

manager-user api-admin

  password cipher @%@%M<2>3XHq%~7|kI,$;qqPV3T[KG'6*0N&I9H\JC<;8US<3T^V@%@%

  service-type api

  level 15

manager-user admin

  password cipher @%@%.VKAL%Xy%77+8>.ME4WF9'R9aubG/-la!0xM$;"wXMm%'R<9@%@%

  service-type web terminal telnet

  level 15

  authentication-scheme admin_local

role system-admin

role device-admin

role device-admin(monitor)

role audit-admin

bind manager-user audit-admin role audit-admin

bind manager-user admin role system-admin

#

l2tp-group default-lns

#

interface GigabitEthernet0/0/0

undo shutdown

ip binding vpn-instance default

ip address 192.168.0.1 255.255.255.0

service-manage http permit

service-manage https permit

service-manage ping permit

#

interface GigabitEthernet1/0/0

undo shutdown

#

interface GigabitEthernet1/0/1

undo shutdown

ip address 10.0.0.2 255.255.255.0

alias inside

service-manage http permit

service-manage https permit

service-manage ping permit

service-manage telnet permit

#

interface GigabitEthernet1/0/2

undo shutdown

ip address 222.190.130.18 255.255.255.248

alias outside

gateway 222.190.130.17

#

interface GigabitEthernet1/0/3

undo shutdown

#

interface GigabitEthernet1/0/4

undo shutdown

#

interface GigabitEthernet1/0/5

undo shutdown

#

interface Virtual-if0

#

interface Cellular0/0/0

#

interface NULL0

#

firewall zone local

set priority 100

#

firewall zone trust

set priority 85

add interface GigabitEthernet0/0/0

add interface GigabitEthernet1/0/1

#

firewall zone untrust

set priority 5

add interface GigabitEthernet1/0/2

#

firewall zone dmz

set priority 50

#

api

#

ip route-static 10.1.1.0 255.255.255.0 10.0.0.1

ip route-static 172.25.0.0 255.255.0.0 10.0.0.1

#

undo ssh server compatible-ssh1x enable

#

firewall detect ftp

#

user-interface con 0

authentication-mode aaa

user-interface vty 0 4

authentication-mode aaa

user-interface vty 16 20

#

pki realm default

#

sa

#

location

#

multi-interface

mode proportion-of-weight

#

right-manager server-group

#

agile-network

#

device-classification

device-group pc

device-group mobile-terminal

device-group undefined-group

#

user-manage server-sync tsm

#

security-policy

rule name T-U

  source-zone trust

  destination-zone untrust

  source-address address-set Office_client

  action permit

rule name L-U

  source-zone local

  destination-zone untrust

  service dns

  service dns-tcp

  service dnsix

  service icmp

  service icmpv6

  action permit

#

auth-policy

#

traffic-policy

#

policy-based-route

#

nat-policy

rule name T-U

  source-zone trust

  destination-zone untrust

  source-address address-set Office_client

  action source-nat easy-ip

#

proxy-policy

#

quota-policy

#

pcp-policy

#

dns-transparent-policy

dns server bind interface GigabitEthernet1/0/2 preferred 218.2.135.1

mode based-on-multi-interface

#

rightm-policy

#

flow-probe-policy

#

mac-access-profile name mac_access_profile

#

sms

#

return
